C
ONFIGURING THE
S
WITCH
2-39
Viewing the Current Spanning Tree Information
The Spanning Tree Information screen displays a summary of the STA
information for the overall bridge or for a specific port. To make any
changes to the parameters for the Spanning Tree, use the Spanning Tree
Configuration menu.
Displaying the Current Bridge STA
The parameters shown in the following figure and table describe the
current Bridge STA Information.
Spanning Tree Information : Selection Menu
==========================================
STA Bridge Information ...
STA Port Information ...
Use or arrow keys to move. to select.
Spanning Tree Information : Bridge STA Information
==================================================
Priority : 32768
Hello Time (in seconds) : 2
Max Age (in seconds) : 20
Forward Delay (in seconds): 5
Hold Time (in seconds)
: 1
Designated Root : 128.0000E800E800
Root Cost : 501
Root Port : 1
Reconfig Counts : 3
Topology Up Time : 48069 (0 day, 1 hr, 2min, 34 sec)
Use or arrow keys to move, to select.
