47
1
Press the Point t button to decrease the contrast; press the Point
u button to increase the contrast (from 0 to 63).
Press the Point t button to decrease the brightness; press the
Point u button to increase the brightness (from 0 to 63).
Press the Point t button to lighten red tone; press the Point u
button to deepen red tone (from 0 to 63).
Press the Point t button to lighten green tone; press the Point u
button to deepen green tone (from 0 to 63).
Press the Point t button to lighten blue tone; press the Point u
button to deepen blue tone (from 0 to 63).
Use the Point t u buttons to select the desired Color temp. level
(XLow, Low, Mid or High).
Press the Point t button decrease the intensity of the color; press
the Point u button increase the intensity of the color (from 0 to 63).
Press the Point t u buttons to adjust the tint value to get a proper
color balance (from 0 to 63).
P Note:
• When White balance Red, Green or Blue is adjusted, the Color temp. level will change to Adj.
• Tint cannot be selected when the video system is PAL, SECAM, PAL-M or PAL-N (p.45).
Image adjust Menu
Selected Image mode
Press the MENU button to display the On-Screen Menu. Use
the Point
pq buttons to select Image adjust and then press
the Point u or the SELECT button.
Use the Point pq buttons select the desired item and then
press the SELECT button to display the adjustment dialog
box. Use the Point
t u buttons to adjust the setting value.
Use the Point t u
buttons to adjust the
setting value.
Video Input
Image Adjustment
Contrast
Brightness
Color
Tint
Color temp .
White balance (Green)
White balance (Red)
White balance (Blue)
