Symbol Technologies VC5090 - Manual (Page 93)

Wireless Applications 4 - 17
Tap
Next
. The
IP Mode
dialog box displays.
IP Mode
Use the
IP Mode
dialog box to configure network address parameters: IP address, subnet, gateway, DNS, and
WINS.
Figure 4-22 IP Config Tab (DHCP)
Select either
DHCP
or
Static
from the drop-down list and tap
Next
. Selecting
Static IP
displays the
IP Address
Entry
dialog box. Selecting
DHCP
displays the
Transmit Power
dialog box.
IP Address Entry
Use the
IP Address Entry
dialog box to enter the IP address and subnet information.
Figure 4-23 Static IP Address Entry Dialog Box
Table 4-12 IP Mode Options
Encryption Description
DHCP Select Dynamic Host Configuration Protocol (DHCP) from the
IP Mode
drop-down list to
obtain a leased IP address and network configuration information from a remote server.
DHCP is the default setting for the vehicle computer profile. When DHCP is selected, the
IP address fields are read-only.
Static Select
Static
to manually assign the IP, subnet mask, default gateway, DNS, and WINS
addresses the vehicle computer profile uses.
