7 - 8
VC5090 Vehicle Computer Product Reference Guide
Defining Script Properties
Before a script is created, the script properties must be defined. This defines the type of vehicle computer,
flash type, number of disks being created and the memory configuration of each disk partition.
To define the script properties:
1.
Select the
Script
window to make it active.
2.
Click the Properties button. The
Script Properties
window -
Partition Data
tab appears.
Figure 7-4
Script Properties Window - Partition Data Tab
3.
In the
Terminal
drop-down list, the
VC5090w
entry is already selected.
4.
Use the default
Flash Type
.
5.
In the
Disks
drop-down list, select the number of disk partitions to create.
Properties button
View/change the current script properties.
Build button
Build the current script into a set of hex files.
Check button
Check the script for errors (files not found).
Send button
Download the hex image to the vehicle computer.
Tile button
Arrange the sub-windows in a tiled orientation.
Build and Send
Build the current script into a set of hex images and send the hex
images to the vehicle computer.
Preferences button
View/change the global TCM options.
Table 7-1
TCM Components (Continued)
Icon
Component
Function
