4 - 16 VC5000 Vehicle Computer Product Reference Guide
Key Entry Page
If you select either
40-Bit WEP
or
128-Bit WEP
the wizard proceeds to the key entry dialog box unless the
Use
Passkey
check box was selected in the
Encryption
dialog box (see
Figure 4-19 on page 4-15
). To enter the key
information:
1.
Enter the 40-bit or 128-bit keys into the fields.
2.
Tap
Next
.
Figure 4-20 40-Bit and 128-Bit WEP Keys Dialog Boxes
Passkey Dialog
When you select
None
as an authentication and
WEP
as an encryption, you can choose to enter a passkey by
checking the
Use PassKey
check box. The user is prompted to enter the passkey. For WEP, the
Use PassKey
checkbox is only available if the authentication is
None .
When you select
None
as an authentication and
TKIP
as an encryption, you must enter a passkey. The user
cannot enter a passkey if the encryption is
TKIP
and the authentication is anything other than
None
.
Figure 4-21 Passkey Dialog Box
Table 4-11 Encryption / Authentication Matrix
Encryption
Authentication Open WEP TKIP
None Yes Yes Yes
EAP TLS No Yes Yes
PEAP No Yes Yes
LEAP No Yes Yes
TTLS No Yes Yes
40-Bit WEP Keys Dialog Box 128-Bit WEP Keys Dialog Box
