VLAN C
OMMANDS
30-18
Command Mode
Global Configuration
Command Usage
• A private VLAN provides port-based security and isolation between
ports within the VLAN. Data traffic on the downlink ports can only
be forwarded to, and from, the uplink port.
• Private VLANs and normal VLANs can exist simultaneously within
the same switch.
• Entering the pvlan command without any parameters enables the
private VLAN. Entering no pvlan disables the private VLAN.
Example
This example enables the private VLAN, and then sets port 12 as the
uplink and ports 5-8 as the downlinks.
show pvlan
This command displays the configured private VLAN.
Command Mode
Privileged Exec
Example
Console(config)#pvlan
Console(config)#pvlan up-link ethernet 1/12 down-link
ethernet 1/5-8
Console(config)#
Console#show pvlan
Private VLAN status: Enabled
Up-link port:
Ethernet 1/12
Down-link port:
Ethernet 1/5
Ethernet 1/6
Ethernet 1/7
Ethernet 1/8
Console#
