SMC Networks SMC TigerAccess SMC7824M/FSW - Manual (Page 121)

S
PECIFYING
T
RAP
M
ANAGERS AND
T
RAP
T
YPES
5-9
Web – Click SNMP, Configuration. Enter the IP address and community
string for each management station that will receive trap messages, specify
the UDP port, SNMP trap version, trap security level (for v3 clients), trap
inform settings (for v2c/v3 clients), and then click Add. Select the trap
types required using the check boxes for Authentication and Link-up/
down traps, and then click Apply.
Figure 5-3 Configuring SNMP Trap Managers
CLI – This example adds a trap manager and enables authentication traps.
Console(config)#snmp-server host 10.1.19.23 private version 2c
udp-port 162 20-6
Console(config)#snmp-server enable traps authentication 20-9
