A
CCESS
C
ONTROL
L
IST
C
OMMANDS
23-18
• tagged-eth2 – Tagged Ethernet II packets.
• untagged-eth2 – Untagged Ethernet II packets.
• tagged-802.3 – Tagged Ethernet 802.3 packets.
• untagged-802.3 – Untagged Ethernet 802.3 packets.
• any – Any MAC source or destination address.
• host – A specific MAC address.
• source – Source MAC address.
• destination – Destination MAC address range with bitmask.
• address-bitmask
27 – Bitmask for MAC address (in hexidecimal
format).
• vid – VLAN ID. (Range: 1-4093)
• vid-bitmask
27 – VLAN bitmask. (Range: 1-4093)
• protocol – A specific Ethernet protocol number. (Range: 600-fff hex.)
• protocol-bitmask
27 – Protocol bitmask. (Range: 600-fff hex.)
Default Setting
None
Command Mode
MAC ACL
Command Usage
• New rules are added to the end of the list.
• The ethertype option can only be used to filter Ethernet II formatted
packets.
• A detailed listing of Ethernet protocol types can be found in RFC
1060. A few of the more common types include the following:
- 0800 - IP
- 0806 - ARP
- 8137 - IPX
27. For all bitmasks, “1” means care and “0” means ignore.
