6 Commissioning
Issue 10/06
MICROMASTER 440
68
Operating Instructions (Compact)
FFB
Input parameters
Output parameters
Setting parameters
AND1
P2810[2]
BI: AND 1 r2811
BO: AND 1
–
AND2
P2812[2]
BI: AND 2 r2813
BO: AND 2
–
AND3
P2814[2]
BI: AND 3 r2815
BO: AND 3
–
OR1
P2816[2]
BI: OR 1 r2817
BO: OR 1
–
OR2
P2818[2]
BI: OR 2 r2819
BO: OR 2
–
OR3
P2820[2]
BI: OR 3 r2821
BO: OR 3
–
XOR1 P2822[2] BI:
XOR 1 r2823
BO: XOR 1
–
XOR2 P2824[2] BI:
XOR 2 r2825
BO: XOR 2
–
XOR3 P2826[2] BI:
XOR 3 r2827
BO: XOR 3
–
NOT1
P2828
BI: NOT 1 r2829
BO: NOT 1
–
NOT2
P2830
BI: NOT 2 r2831
BO: NOT 2
–
NOT3
P2832
BI: NOT 3 r2833
BO: NOT 3
–
D-FF1
P2834[4]
BI: D-FF 1 r2835
BO: Q D-FF 1
r2836
BO: NOT-Q D-FF 1
–
D-FF2
P2837[4]
BI: D-FF 2 r2838
BO: Q D-FF 2
r2839
BO: NOT-Q D-FF 2
–
RS-FF1 P2840[4]
BI: RS-FF 1 r2841
BO: Q RS-FF 1
r2842
BO: NOT-Q RS-FF 1
–
RS-FF2 P2843[4]
BI: RS-FF 2 r2844
BO: Q RS-FF 2
r2845
BO: NOT-Q RS-FF 2
–
RS-FF3 P2846[4]
BI: RS-FF 3 r2847
BO: Q RS-FF 3
r2848
BO: NOT-Q RS-FF 3
–
Timer1 P2849
BI:
Timer
1 r2852 BO:
Timer
1
r2853
BO: NOT Timer 1
P2850 Delay time of Timer 1
P2851
Mode Timer 1
Timer2 P2854
BI:
Timer
2 r2857 BO:
Timer
2
r2858
BO: NOT Timer 2
P2855 Delay time of Timer 2
P2856
Mode Timer 2
Timer3 P2859
BI:
Timer
3 r2862 BO:
Timer
3
r2863
BO: NOT Timer 3
P2860 Delay time of Timer 3
P2861
Mode Timer 3
Timer4 P2864
BI:
Timer
4 r2867 BO:
Timer
4
r2868
BO: NOT Timer 4
P2865 Delay time of Timer 4
P2866
Mode Timer 4
ADD1
P2869[2]
CI: ADD 1 r2870
CO: ADD 1
–
ADD2
P2871[2]
CI: ADD 2 r2872
CO: ADD 2
–
SUB1
P2873[2]
CI: SUB 1 r2874
CO: SUB 1
–
SUB2
P2875[2]
CI: SUB 2 r2876
CO: SUB 2
–
MUL1
P2877[2]
CI: MUL 1 r2878
CO: MUL 1
–
MUL2
P2879[2]
CI: MUL 2 r2880
CO: MUL 2
–
DIV1
P2881[2]
CI: DIV 1 r2882
CO: DIV 1
–
DIV2
P2883[2]
CI: DIV 2 r2884
CO: DIV 2
–
CMP1
P2885[2]
CI: CMP 1 r2886
BO: CMP 1
–
CMP2
P2887[2]
CI: CMP 2 r2888
BO: CMP 2
–
FSW1
–
–
P2889
CO: FSW 1 in [%]
FSW2
–
–
P2890
CO: FSW 2 in [%]
