Jackson AJ-100 User Manual
Page 93
AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 6: ELECTRICAL SCHEMATICS
D226 STEAM BOOSTER/DRAIN QUENCH SYSTEM/SIDE LOADER
145
E1
E2
FS1
TS1
S1
S1
L2
L1
GND
OFF
OFF
ON
ON
TS1: THERMOSTAT
FS1: SOLENOID COIL
S1: POWER SWITCH
E1: POWER LIGHT
E2: SOLENOID LIGHT
D226/J120 STEAM BOOSTER OPTION
120/200/208/230 VOLT - 60 HZ - 1PH
09905-002-78-56 D
Drain Quench System
64” CONVEYORS
86” & 100” CONVEYORS
