AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
102
CURTAINS/TUB MAGNETS
Curtain, 21” Long x 20-1/2” Wide
08415-131-73-45
Curtain, 12” Long x 20-1/2” Wide
08415-131-73-44
Curtain Rod
05700-021-73-43
Long Curtain Decal
09905-011-73-84
Short Curtain Decal
09905-011-73-82
Curtain, 24 1/2” Long x 20-1/2” Wide
CGP MODELS ONLY
08415-002-47-37
Extra Long Curtain Decal
CGP MODELS ONLY
09905-002-52-69
Middle Curtain Hook
05700-011-72-65
Curtain Hook
05700-011-83-54
Limit Switch Bracket
05700-021-71-18
Conveyor Switch Replacement Kit
06401-003-11-79
Replacement Kit Note:
The conveyor switch replacement kit
comes with the switch, a terminal and
a wire nut.
Service Note:
The cord for the conveyor switch needs to be cut to length in the field
and have the pink terminal applied there.
