AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
65
INCOMING PLUMBING ASSEMBLY(CONTINUED)
ITEM QTY DESCRIPTION Mfg. No.
1 1 Injector, Rinse Weldment (L-R all units) 05700-021-67-98
1 1 Injector, Rinse Weldment (R-L CGP units only) 05700-002-57-87
2 2 Fill Line, Injector 05700-011-67-99
3 3 Plug, 1/8” NPT, Brass 04730-209-07-37
4 3 Vacuum Breaker, 3/4” NPT, Brass 04820-002-53-77
5 5 Elbow, 3/4” NPT, Street, Brass 04730-206-04-34
6 6 Nipple, 3/4” NPT, Close, Brass 04730-207-34-00
7 3 Valve, Solenoid, 3/4” NPT, 110 Volt 04810-100-53-00
8 3 Union, 3/4” NPT, Brass 04730-212-05-00
9 4 Adapter, 3/4” Male 04730-401-11-01
10 2 Tee, Copper, 3/4” CU x CU x CU 04730-411-46-01
11 1 Tube, Copper, 3/4” x 3” Long 05700-000-54-85
12 2 Nipple, 3/4” NPT, Brass, 6” Long 05700-001-26-74
13 2 Tee, Copper, 3/4” x 3/4” x 1/2” 04730-411-03-01
14 2 Adapter, Threaded, 1/4” 04730-401-41-01
15 1 Valve, Ball, Test Cock, 1/4” NPT 04810-011-72-67
16 1 Gauge, 0-100 PSI 06685-111-88-34
1 Decal, 15-25 PSI 09905-002-97-74
17 2 Tube, 3/4” x 2-13/16” Long 05700-011-72-72
18 1 Plug, 1/4” 04730-209-01-00
19 1 Regulator, Pressure, 3/4” NPT (Not used on CGP models) 06685-011-58-22
19a 1 Elbow, 3/4” 90 ° Brass (Used on CGP models only) 04730-206-13-00
20 1 Tube, 3/4” x 9” Long 05700-000-75-61
21 1 Tube, 3/4” x 16-1/4” Long 05700-011-31-48
22 2 Tube, 3/4” x 5-1/2” Long 05700-002-61-46
