AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
103
VENT COWL ASSEMBLY/VENT SCOOP OPTION
Vent Cowl Cover Replacement Kit
06401-003-10-16
Gasket, Top Vent Cowl
05330-031-83-47
Vent Cowl Replacement Kit
06401-003-11-62
Gasket, Side Vent Cowl
05330-031-83-48
VENT SCOOP OPTION
Replacement Kit Note:
The kit for the vent cowl comes with the vent
cowl weldment, new gaskets and the lock-
nuts needed to mount it.
Vent Scoop Assembly
05700-002-04-08
