Jackson AJ-100 User Manual
Page 11
AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
63
PREWASH PLUMBING ASSEMBLY
Y-Strainer, 3/4” NPT,
Brass
04730-717-02-06
Nipple, 3/4”, Brass, Close
04730-207-34-00
Valve, Solenoid, 3/4”
04810-100-53-00
Nipple, 3/4”, Brass, Close
04730-207-34-00
Vacuum Breaker, 3/4”
04820-002-53-77
Elbow, 90
°, 3/4” Brass
04730-206-04-34
Elbow, 90
°, 3/4” Brass
04730-206-04-34
Nipple, 3/4” x 6” Long
05700-001-26-74
Fill Line Injector
05700-011-67-99
A new gasket can be
ordered using part num-
ber 05330-111-42-81.
