1.2
Getting started
Packaging contents
Included in your machine’s packaging:
❑ Main unit with 400-sheet paper cassette installed
❑ Document hopper
❑ Paper size stickers
❑ Paper tray ❑ One-touch labels
❑ Multi paper tray ❑ Soft Key labels
❑ Telephone line cord ❑ Operating instructions
❑ AC power cord ❑ Protection seals (This seal may actually be
❑ Drum cartridge used when your authorized dealer installs
❑ Toner cartridge your fax machine.)
❑ Fuser cleaner
Note: Be sure to save the box (or boxes) and packing materials for reshipment.
Parts of the Fax
Note: Any terms used here that are unclear to you right now will be explained in
detail in the coming pages.
1 Liquid crystal display ( LCD ) — Shows the machine’s status and lets you
see what you’re programming into the machine. The display shows 2 lines, 20
characters per line. If the
LCD is blank, the machine is off.
2 Control Panel — The keys you use to operate your fax machine. (See pages
1.4–1.6 for more details.)
3 Paper cassette — One of two locations where you put the recording paper
(the Multi paper tray is the other). Holds up to 400 sheets, either letter or
legal-sized paper.
4 Recording paper level indicator — Shows the level of the current paper
supply without requiring you to open the paper cassette.
5 Original document exit — Where your original document comes out after
being scanned.
