Just in case …
If a printout jams inside your machine
To clear a printout jammed inside your machine:
1 Open the top cover.
2 Open the printer cover.
3 Remove the toner and drum cartridge.
Important: Shield the drum cartridge
from light, especially
strong light. Later, if you
have to remove the car-
tridge from the fax,
immediately wrap it in a
thick cloth to protect it
from light.
4 Remove the jammed paper.
Important: The fuser unit of orange
color becomes very hot.
Do not touch the fuser
unit when you are remov-
ing a paper jam.
Note: Avoid getting “unfixed” toner on
your hands and clothes.
5 Re-set the toner and drum cartridge.
6 Gently close the printer cover.
7 Gently close the top cover, pressing firmly on the both sides of the top cover
until you hear it click.
