Parts and Functions

1-4

User’s Manual

INSIDE

SIDES (left side shown)

Figure 1–4

Parts (2)

!8 Print head

!7 Ribbon cassette

!9 Platen

@0 Paper thickness lever

@2 Lock lever

@1 Jam removal lever

@3 Tractor

@4 Center guide
