5. CALLING, RECEIVING
5-21
11. Push the [ENTER] knob to open the DSC FREQ menu.
12M-INTL
GO TO ALL VIEW
CALL TYPE:
AREA:
PRIORITY
COM. TYPE
COM. FREQ Individual
001234567
: Routine
: Telephone
: No infor
6 MHZ
8 MHZ
$
12 MHZ
4 MHZ
2 MHZ
DSC FREQ : TL
16 MHZ
18 MHZ
22 MHZ
25 MHZ
OTHER
Rotate the [ENTER]
knob to scroll.
OTHER: Special, private channels.
** Compose message **
12. Rotate the [ENTER] knob to choose DSC band desired and then push the [ENTER]
knob.
13. Rotate the [ENTER] knob to choose DSC frequency desired and then push the
[ENTER] knob. (See “How to set DSC frequency” on page 5-7 for details.) Your display
should now look something like one below.
CALL TYPE : AREA CALL
AREA : 12
°
N 123
°
W
↓
10
° →
5
°
PRIORITY : ROUTINE
COM. TYPE : TELEPHONE
COM. FREQ :
2164.0 KHZ
DSC FREQ : 2177.0 KHZ
GO TO ALL VIEW
** Compose message **
14. Press the [CALL] key to send the geographical area call (transmission time: about 7
sec.). The display shows "Geographical area call in progress!" while the call is being
sent.
AREA: 12
°
N 123
°
W
↓
10
° → 5 °
Geographical area
call in progress!
TIME TO GO : 7S
DSC FREQ : 2177.0 KHZ
TELEPHONE 2164.0 KHZ
ROUTINE
15. After the call is sent the radiotelephone screen appears. If you chose radiotelephone at
step 8, you can now communicate with the other party. For NBDP, do the following:
Sending message by NBDP Terminal Unit
1. Press the function key [F3] on the keyboard of the NBDP Terminal Unit to show the
Operate menu.
2. Call Station is selected; press the [Enter] key.
3. DSC is selected; press the [Enter] key.
4. “Connect” will be highlighted. Type and transmit your message.
5. Press the function key [F10] (BREAK) to disconnect the line.
.
