APPENDIX
AP-22
Parts List
This equipment contains complex modules in which fault diagnosis and repair down to
component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components
are used. FURUNO Electric Co., Ltd. Believes identifying these components is of no value
for shipboard maintenance; therefore, they are not listed in this manual. Major modules
can be located on the parts location photos on pages AP-25 thru AP-27.
Control unit FS-1570/2570
F U R U N O
Model FS-1570/2570
Unit
CONTROL UNIT
ELECTRICAL PARTS LIST
Aug-02 Blk.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
B2 05P0728, PANEL 005-951-870 X
B3 05P0729, C-CPU 005-951-880 X
B4 05P0730, C-IF 005-951-890 X
