2 SSB RADIOTELEPHONE

2-5

2.1.6 Reducing transmitter power

To conserve energy and to minimize possible interference to other stations, reduce the
transmission power. This should be done when using the transceiver in a harbor, near the
shore or close to communication partner (other ship).

1. Rotate the [ENTER] knob to choose LOW, MID or HIGH (whichever is shown) at the

top of the screen and then push the [ENTER] knob.

FS-1570 FS-2570

LOW 68 W 70 W

MID 100 W 125 W

HIGH 150 W 250 W

MODE: SSB SIMP HIGH

CH: 200

TX: 2182.0

KHZ

RX: 2182.00

KHZ

VOL

SEN

AGC : FAST

2.1A

LOW

MID
HIGH

2. Rotate the [ENTER] knob to choose power among LOW, MID and HIGH as

appropriate and then push the [ENTER] knob.

Note:

Power amplifier temperature is monitored, and when its temperature rises above a

certain temperature output power is automatically reduced.

2.1.7 Displaying IA, IC, VC or RF

While transmitting, you may display RF (PA output), IA (antenna current), IC (collector
current) or VC (collector voltage), at the lower right corner of the radiotelephone screen.

1. Rotate the [ENTER] knob to choose RF, IA, IC or VC, whichever is displayed at the

bottom right corner.

2. Push the [ENTER] knob.
