11 NBDP TRANSMITTING, RECEIVING
11-7
Type a message from the keyboard
After exchanging answerback code by the function key [F7] (WRU) and [F8] (HR), type your
message directly from the keyboard.
5. To change direction of traffic, press either function key [F9] (OVER), or [+] and [?]. Then,
the other station becomes the information sending station, your station the information
receiving station.
6. Receive a message from the sending station, if any.
7. After completion of communication, press the function key [F7] (WRU) key to receive the
answerback code of the other station and then press the function key [F8] (HR) to
transmit your own answerback code.
8. Press the function key [F10] (Break) to disconnect the line.
11.6 FEC Mode Operation
The FEC method of error correction is used when there is more than one receiving station,
and no replies are required by the other station. Each message is sent twice, the characters
of the first message interleaved with those of the second. The receiving station thus has two
chances to receive each character correctly. If both characters are in error, an asterisk (*) is
printed.
1. Press the function key [F3].
2. Press the [1] key to display the Call Station menu.
You can choose scan group by scan table.
3. Choose a station which is registered for the FEC mode. Press the [Enter] key.
“CONNECT” appears in reverse video.
4. Transmit a message directly from the keyboard, or do the following to transmit a
message stored on a floppy disk:
Press the function key [F3] and the [2] key to open the Send screen. Choose file to send and
then press the [Enter] key.
5. After the message is transmitted, press the function key [F10] (Break) to disconnect the
line.
