5. CALLING, RECEIVING
5-7
** Compose message **
How to Set DSC Frequency
GO TO ALL VIEW
CALL TYPE INDIVIDUAL
STATION ID 123456789
PRIORITY ROUTINE
COM. TYPE TELEPHONE
COM. FREQ NO INFO
: Individual
: 001234567
: Routine
: Telephone
: No infor
DSC FREQ TL : 12M-INTL
16 MHZ
18 MHZ
22 MHZ
25 MHZ
#
OTHER
6 MHZ
8 MHZ
$
12 MHZ
4 MHZ
2 MHZ
** Compose message **
Routine or ship’s business priority
1. Rotate the [ENTER] knob to choose DSC FREQ and then push the [ENTER] knob.
2. Rotate the [ENTER] knob to choose appropriate DSC band and then push the [ENTER] knob.
One of the menus shown below appears depending on the band selected.
GO TO ALL VIEW
CALL TYPE
Station ID
Priority
Com. type
COM. FREQ
: Individual
: 001234567
: Routine
: Telephone
: No infor
: 12M-INTL
6 MHz
8 MHz
12 MHz
4 MHz
#
USER CH1 : T12345.0/R12345.0
USER CH2 : T12345.5/R12345.5
USER CH3 : T12346.0/R12346.0
USER CH4 : T12346.5/R12346.5
Rotate the [ENTER] knob
to scroll menu if user channels
are registered.
12MHz menu
INTL :T 12577.5/R12657.0
LOCAL1 :T 12578.0/R12657.5
LOCAL2 :T 12578.5/R12658.0
16MHz menu
INTL :T 16805.0/R16903.0
LOCAL1 :T 16805.5/R16903.5
LOCAL2 :T 16806.0/R16904.0
2MHz menu
INTL :T 2189.5/R 2177.0
4MHz menu
INTL :T 4208.0/R 4219.5
LOCAL1 :T 4208.5/R 4220.0
LOCAL2 :T 4209.0/R 4220.5
6MHz menu
INTL :T 6312.5/R 6331.0
LOCAL1 :T 6313.0/R 6331.5
LOCAL2 :T 6313.5/R 6332.0
8MHz menu
INTL :T 8415.0/R 8436.5
LOCAL :T 8415.5/R8437.0
LOCAL :T 8416.0/R8437.5 18MHz menu
INTL :T18898.5/R19703.5
LOCAL1 :T18899.0/R19704.0
LOCAL2 :T18899.5/R19704.5
22MHz menu
INTL :T 22374.5/R22444.0
LOCAL1 :T 22375.0/R22444.5
LOCAL2 :T 22375.5/R22445.0
25MHz menu
INTL :T 25208.5/R26121.0
LOCAL1 :T 25209.0/R26121.5
LOCAL2 :T 25209.5/R26122.0
Other menu
INTL :T 458.5/R 458.5
2 MHz
D SC FREQ
INTL : T12577.5/R12657.0
LOCAL1 : T12578.0/R12657.5
LOCAL2 : T12578.5/R12658.0
$
LOCAL = Local channel
** Compose message **
3. Rotate the [ENTER] knob to choose DSC frequency and then push the [ENTER] knob. The
display shows the DSC frequency band selected, at "DSC FREQ".
Safety or urgency priority
For safety or urgency priority "COM. FREQ" is automatically set to the same pair frequency as the
DSC frequency.
1. Rotate the [ENTER] knob to choose DSC FREQ and then push the [ENTER] knob.
GO TO ALL VIEW
CALL TYPE:
STATION ID:
PRIORITY
COM. TYPE
INDIVIDUAL
001234567
: SAFETY
: TELEPHONE
DSC FREQ : 2187.5 KHZ
COM. FREQ : 2182.0KHZ
4207.5
6312.0
8414.5
12577.0
16804.5
2187.5
2. Rotate the [ENTER] knob to choose appropriate frequency and then push the [ENTER] knob.
Rotate the [ENTER]
knob to scroll.
OTHER: Private channel
