FUJITSU DL9300 - Manual (Page 173)

PRINTER AND PAPER SPECIFICATIONS
B-6
User's Manual
PAPER SPECIFICATIONS
Print Area
This section illustrates the recommended print area for single sheets
and continuous forms.
Print area for single sheets
May be
decreased to
4.23 mm
(1/6 inch).
However, line
spacing may be
uneven.
Print area may be
off the paper,
depending on
paper setting or
width.
4.73 mm (0.18 inch)
4.73 mm (0.18 inch)
Print area
5.08 mm or more
(0.2 inch or more)
H H
H H
55-266.7 mm (2.16-10.5 in)
for 80-column printer
55–420 mm (2.16–16.5 in)
for 136-column printer
70-364 mm (3-14.3 in)
for 80-column printer
70–420 mm (3–16.5 in)
for 136-column printer
5.08-38 mm (0.2-1.5 in)
