Setting Up
SETTING UP
User's Manual 2-13
GETTING ACQUAINTED
WITH YOUR PRINTER Now that your printer is assembled, take a moment to become familiar
with its major parts.
Looking at the printer from the front right side, you can see the parts of
the printer shown in the figure below.
Printer components
The printer control panel has the buttons and indicators used to load
and feed paper (see Chapter 3) and select print features (see Chapter
4). The control panel also allows you to change the printer’s optional
settings (see Chapter 5).
Paper guide
Power switch
Paper table
Tractor unit
Front CSF connector
Platen
Front
cover
Print guide
Print head
Paper thickness
indicator
Rear CSF connector Rating label
Power
connector
Interface
connector
Control panel
Rear stacker
