PAPER HANDLING
3-19
4. Release the tractor locking levers by pulling them up. Open the
tractor paper holders. See the following figure.
5. Position the left tractor. Push the left locking lever down to
secure the tractor. Center the middle forms support.
Positioning the tractors
6. Adjust the left margin.
Below the left tractor, there is a tractor guide, short inch-based
ruler graduated in 10 columns per inch. Use the ruler to help
position the tractor. When the paper edge is positioned to the
zero line, the left margin is 12 mm (0.5 inch) including perfora-
tion area and the arrow indicates the location of the first
character.
Middle forms
support
Release
Locking lever
Locking lever
