DRIVE TRAIN
Front Axle Assy
Starting Serial No. 0155259
Original Issue 1-98
6-12
Item
Part No.
Qty.
Description Of Part
9104-3291
1
FRONT AXLE ASSY (includes items 1
thru 4)
1
9104-4444
1
AXLE HOUSING ASSY (see page 6-13
for details)
2
9104-4448
1
DIFFERENTIAL CARRIER ASSY (see
page 6-14 for details)
3
9103-4309
1
AXLE SHAFT & PLANETARY WHEEL
END ASSY (see page 6-15 for details)
4
8319-3009
4
FITTING
5
9104-3146
24
LUG NUT
