Item Part No. Qty. Description Of Part
9104-3064 1 HYDRAULIC CONTROLER ASSY
(includes all items)
9900-7524 4 PLUNGER SEAL KIT (includes one
each of the following; u-cup, o-ring
seal, retainer & o-ring)
1 9104-4131 1 HYDRAULIC CONTROLLER
2 9104-4132 1 RETAINING RING
3 9104-4133 1 WASHER
4 9104-4134 1 BOOT
5 9104-4135 1 RETAINER
6 9104-4136 1 HANDLE ASSY (includes knob, handle
rod & hex jam nut)(lubricate & tighten
jam nut to 12-15 ft. lbs.)
7 9104-4474 1 BALL ASSY (includes ball pivot race,
ball pivot, cam plate, handle adapter &
top mounting plate)
*8 9104-4525 1 KNOB
10-29 * Added item 8.
HYDRAULIC COMPONENTS
Hydraulic Controller
Starting Serial No. 8655105G
Original Issue 8-86
Revised 1-3-96
