Page 130
9-12
Item
Part No.
Qty.
Description Of Part
1
Ref
TILT CYLINDER ASSY (see page
10-4 for details)
2
8867-1008
1
LUBE FITTING, STRAIGHT, 1/4-28
3
8867-1027
1
LUBE FITTING, 45 DEGREES, 1/4-28
4
9020-6892
3
PIN
5
8320-1044
1
HEX HD CAPSCREW
6
8852-1010
3
HEX LOCKNUT, 5/8-11
7
8866-2106
2
ELBOW, 90 DEGREES (swivel nut)
8
8866-2020
2
STRAIGHT THREAD CONNECTOR
(includes item 9)
9
8859-1207
2
O-RING
10
8471-7916
2
HOSE ASSY
11
8866-1065
3
UNION, 1/2 TUBE
12
8471-7486
2
HOSE ASSY
13
7713-3136
1
CLAMP SET
14
8820-1023
1
HEX HD CAPSCREW, 5/16-18X1-3/4,
GR5
15
7713-3137
1
COVER PLATE
16
9104-3098
1
TUBE ASSY
17
8820-1038
2
HEX HD CAPSCREW, 3/8-16X1-3/4,
GR5
18
8856-1109
4
FLAT WASHER, 3/8
19
9104-1226
4
SPACER
20
8855-1011
4
LOCKWASHER, 3/8
21
8850-1006
2
HEX NUT, 3/8-16
22
9104-3093
1
HOSE CARRIER
23
8820-1003
8
HEX HD CAPSCREW, 1/4-20X3/4,
GR5 (lubricate & torque to 9-12 ft.lbs.)
24
8856-1107
8
FLAT WASHER, 1/4
25
8820-1037
2
HEX HD CAPSCREW, 3/8-16X1-1/2,
GR5
26
8471-7494
2
HOSE ASSY
27
8855-1009
4
LOCKWASHER, 1/4
Item
Part No.
Qty.
Description Of Part
28
9002-7180
2
BULKHEAD ELBOW, 90 DEGREES,
1/2 TUBE
29
9002-7180
2
BULKHEAD FITTING, 90 DEGREES
30
9040-3249
2
HOSE TAKE-UP WELDMENT
31
9020-0313
2
SPRING
32
9020-7041
2
SPRING RETAINER
33
8850-1008
2
HEX NUT, 1/2-13
34
8850-1108
2
HEAVY HEX JAM NUT, 1/2-13
35
Ref
PUSH BEAM & CABLES (see page
3-5 for details)
36
9105-3413
12
CUSHION CLAMP
37
8471-7503
2
HOSE ASSY
38
8866-2106
2
ELBOW, 90 DEGREES (swivel nut)
39
8820-1104
2
HEX HD CAPSCREW, 5/8-11X3-3/4,
GR5
40
Ref
COMPENSATING CYLINDER ASSY
(see page 10-5 for details)
41
9002-2043
2
HOSE ASSY
42
8866-2021
1
CONNECTOR (includes item 43)
43
8859-1205
1
O-RING
44
8866-2107
3
ELBOW, 90 DEGREES (swivel nut)
45
9020-7386
1
TUBE ASSY
46
9020-7387
1
TUBE ASSY
47
9103-3032
2
MINI-CHECK COUPLING
48
Ref
MAIN CONTROL VALVE (see page
10-10 for details)
49
9002-9939
2
BULKHEAD UNION
50
9002-2043
2
HOSE ASSY
51
8866-2107
3
ELBOW, 90 DEGREES (swivel nut)
52
8866-2008
1
CONNECTOR (includes item 53)
53
8859-1207
2
O-RING
54
8692-3006
1
REDUCER/EXPANDER FITTING
55
8866-2022
1
CONNECTOR (includes item 53)
HYDRAULIC CIRCUITS
Tilt Cylinder
Starting Serial No. 0155283
Original Issue 11-89
Revised 8-18-00
*
DS
* Revised part number on items 28 & 47.
*
