System board

Description

Spare part number

For use only with computer models equipped with WWAN

441097-001

For use only with computer models not equipped with WWAN

441096-001

When replacing the system board, be sure that the following components are removed from the defective

system board and installed on the replacement system board:

Memory module (see

Memory module on page 43

)

WLAN module (see

WLAN module on page 44

)

RTC battery (see

RTC battery on page 62

)

Bluetooth module (see

Bluetooth module on page 65

)

Fan/heat sink assembly (see

Fan/heat sink assembly on page 71

)

Processor (see

Processor on page 74

)

Before removing the system board, follow these steps:

1

.

Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2

.

Disconnect all external devices connected to the computer.

3

.

Disconnect the power cord.

4

.

Remove the battery (see

Battery on page 36

).

5

.

Remove the following components:

a

. Hard drive (see

Hard drive on page 38

)

b

. Memory module compartment cover (see

Memory module on page 43

)

c

. Optical drive (see

Optical drive on page 42

)

d

. Keyboard (see

Keyboard on page 47

)

e

. Switch cover (see

Switch cover on page 50

)

f

.

Display assembly (see

Display assembly on page 52

)

g

. Top cover (see

Top cover on page 59

)

h

. Power switch assembly (see

Power switch assembly on page 63

)

Remove the system board:

1

.

Disconnect the ZIF connector (1) to which the audio/infrared board cable is attached and disconnect

the audio/infrared board cable (2) from the system board.

2

.

Press in on the ExpressCard slot bezel (3) to release the bezel from the ExpressCard slot.
