Switch cover
Description Spare part number
Switch cover (includes display convertible hinge base cover) 441135-001
Before removing the switch cover, follow these steps:
1 . Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2 . Disconnect all external devices connected to the computer.
3 . Disconnect the power cord.
4 . Remove the battery (see Battery on page 36 ).
5 . Remove the keyboard (see Keyboard on page 47 .)
Remove the switch cover:
1 . Turn the computer upside down, with the front toward you.
2 . Remove the four Phillips PM2.0×7.0 screws that secure the switch cover to the computer.
3 . Turn the computer display-side up, with the front toward you.
4 . Open the computer.
50 Chapter 5 Removal and replacement procedures ENWW
