HP TX1000 User Manual
Page 59
7
.
Disconnect the display assembly cables (2) and (3) from the system board.
8
.
Turn the computer display-side up, with the front toward you.
9
.
Open the computer.
10
.
Remove the display convertible hinge cover (1).
11
.
Remove the two Phillips PM2.5×6.0 screws (2) that secure the display assembly to the computer.
12
.
Disconnect the display panel cable (3) from the system board.
NOTE:
As you remove the display assembly, be sure that the display cables and wireless
antenna cables move cleanly through the opening (1) in the computer.
54 Chapter 5 Removal and replacement procedures
ENWW
