Power switch assembly

Description

Spare part number

Power switch assembly (includes power switch board cable and actuator switch)

441142-001

Before removing the power switch assembly, follow these steps:

1

.

Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2

.

Disconnect all external devices connected to the computer.

3

.

Disconnect the power cord.

4

.

Remove the battery (see

Battery on page 36

).

5

.

Remove the following components:

a

. Hard drive (see

Hard drive on page 38

)

b

. Optical drive (see

Optical drive on page 42

)

c

. Keyboard (see

Keyboard on page 47

)

d

. Switch cover (see

Switch cover on page 50

)

e

. Display assembly (see

Display assembly on page 52

)

f

.

Top cover (see

Top cover on page 59

).

Remove the power switch assembly:

1

.

Remove the two Phillips PM2.0×4.0 screws (1) that secure the power switch board to the base

enclosure.

2

.

Remove the Phillips PM2.0×4.0 screw (2) that secures the display release hook assembly to the base

enclosure.
