Print Quality

6-8

HP DesignJets 1050C and 1055CM Printers Service Manual

Below are shown two examples of alignment and misalignment:

Solving the Color Alignment Problem

1 Make sure you have media loaded (not clear film, vellum or tracing

paper).

2 Go to the printer submenu and press Enter.

3 Perform the Printhead Alignment Calibration by going to Utilities/

Calibration/Printhead Alignment. Please wait as the process of
aligning the printheads takes a few minutes.

4 Reprint the image you were attempting to print before (in the same

mode) to see if the problem still exists.

5 Perform the Color to Color Calibration

⇒

Page 5-16.

correct

Incorrect

C6074276

Ready

MAGENTA
YELLOW
BLACK

CYAN

Ink

Printer submenu

Utilities

Calibrations

Printhead Alignment
