Service Tests and Utilities
4-30
HP DesignJets 1050C and 1055CM Printers Service Manual
8 Once the tubes system is purged, the following message will be
displayed. Lift the window and remove ALL the Setup Printheads
from the carriage and install the previously removed printing
Printheads into the carriage.
9 Once all the Printheads are installed, the following message will
appear on the front panel. Close the carriage cover and close the
window.
10 Open the right cover and make sure the Printhead Cleaners are
installed in the Service Station.
11 If media is not loaded, the following message appears on the front
panel and you must load media into the Printer.
INK STARTUP
Lift window to
replace SETUP
printheads
INK STARTUP
All printheads
are OK. Close cover
and window to
continue
INK STARTUP
Open right cover
and install printhead
cleaners
INK STARTUP
calibration
Load paper for
