Service Calibrations
5-2
HP DesignJets 1050C and 1055CM Printers Service Manual
Service Calibrations
The Printer has several calibration procedures that must be
performed under certain conditions. Refer to the table below to
determine when calibrations are required.
WARNING
REMEMBER THAT CERTAIN CALIBRATIONS ARE
REQUIRED EVEN IF AN ASSEMBLY HAS BEEN
DISASSEMBLED TO GAIN ACCESS TO ANOTHER
ASSEMBLY OR COMPONENT.
NOTE
Refer to the following page for the relevant Calibration.
Which Calibrations Need To Be
Done
When Required
1
2
3
4
5
6
7
8
♦
Carriage is disassembled or
replaced
No
Yes
Yes
Yes
No
Yes
No
Yes
Yes
Electronics Module is
replaced
No
No
No
No
No
No
Yes
Yes
No
Paper-Axis is disassembled
or replaced
Yes
No
No
No
No
Yes
No
No
No
Platen Assembly is
disassembled or replaced
No
No
Yes
No
No
Yes
No
No
Yes
Service Station is
disassembled or replaced
No
No
Yes
No
No
Yes
No
No
No
Drive Roller is
disassembled or replaced
Yes
No
No
No
No
Yes
No
No
No
Tubes System (SRK) is
disassembled or replaced
No
No
No
No
No
No
Yes
Yes
No
Banding Problem
Yes
Yes
No
No
No
No
No
Yes
No
Misalignment between
Colors
No
Yes
No
No
No
Yes
No
Yes
No
Color Accuracy Problem
No
No
No
No
No
No
No
No
No
Edge Detect Problems
No
Yes
No
No
No
No
No
No
No
