4800dr Barcode Guide 6 - 13
Code 128 Message Length
Scan the barcodes below to change the message length. Refer to Message Length Description (page 6-1) for additional
information. Minimum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.
Code 128 Code Page
Code pages define the mapping of character codes to characters. If the data received does not display with the proper
characters, it may be because the barcode being scanned was created using a code page that is different from the one the host
program is expecting. If this is the case, scan the barcode below, select the code page with which the barcodes were created
(see Code Page Mapping of Printed Barcodes on page A-4), and scan the value and the Save barcode from the Programming
Chart on the inside the back cover of this manual. The data characters should then appear properly.
Telepen
Telepen
Telepen Output
Using AIM Telepen Output, the document reader reads symbols with start/stop pattern 1 and decodes them as standard full
ASCII (start/stop pattern 1). When Original Telepen Output is selected, the document reader reads symbols with start/stop
pattern 1 and decodes them as compressed numeric with optional full ASCII (start/stop pattern 2). Default = AIM Telepen Output.
Minimum Message Length
Maximum Message Length
Code 128 Code Page
On
* Off
Original Telepen Output
* AIM Telepen Output
