4800dr Barcode Guide 11 - 1
11
Product Specifications
Parameter Specification
Dimensions (Typical):
Height (excluding cable) 15.13 inches (38.43 cm)
Depth 14.47 inches (36.75 cm)
Width 13.39 inches (34.01 cm)
Weight (typical):
Imager
Stand
3 oz. (85g)
4 lbs. 6 oz. (1.98kg)
Illumination Sources:
Illumination LEDs
Aiming Laser White, 440nm and 530nm at < 650μW
Red, 645nm - 660nm at < 1mW
Image 1280x960 binary. TIFF, JPEG or BMP output.
Skew Angle +45 degrees
Pitch Angle +45 degrees
Motion Tolerance - 100% UPC 3 inches (7.62cm) per second
Symbol Contrast Grade 1.0 (20% or greater)
Voltage Requirements 4 - 5.5 VDC at imager
Current Draw (Typical): Scanning 370mA. Inrush 500mA.
Power Supply Noise Rejection Max. 100 mV peak to peak, 10 to 100 KHz
Temperature Ranges:
Operating
+32°F to +122°F (0°C to +50°C)
Storage -4°F to +140°F (-20°C to +60°C)
Humidity 5 to 95% at 50°C, non-condensing
Mechanical Drop - Imager
Operational after 50 drops from 5 feet
(1.524m) to concrete
Vibration - Imager Withstands 5G peak from 22 to 300 Hz
ESD Tolerance 15Kv
Agency Compliance
General:
CB Scheme: IEC60950-1 I.T.E.
LED Safety: Class 1 IEC 60825-1
Laser Safety: Class 2 IEC 60825-1
USA:
FCC Part 15, Subpart B: Class B
UL: 60950-1 I.T.E.
CDRH: Laser Class 2
Canada:
cUL: CSA C22.2 No. 60950-1 I.T.E.
CAN/CSA-CEI/IEC CISPR 22-02: Class B
European Community:
2004/108/EC EMC Directive
2006/95/EC Low Voltage Directive
Germany:
Gebprüfte Sicherheit (GS) marked and certified
Australia:
C-Tick marked for AS/NZS 3548
