1 - 4 4800dr Barcode Guide
USB PC or Macintosh ® Keyboard
Scan one of the following codes to program the document reader for USB PC Keyboard or USB Macintosh Keyboard. Scanning
these codes adds a CR and selects the terminal ID (USB PC Keyboard - 124, USB Macintosh Keyboard - 125).
USB HID
Scan the following code to program the document reader for USB HID barcode readers. Scanning this code changes the terminal
ID to 131.
USB COM Port Emulation
Scan the following code to program the document reader to emulate a regular TTL-232-based COM port. If you are using a
Microsoft® Windows® PC, you will need to download a driver from the Hand Held Products website ( www.handheld.com ) . The
driver will use the next available COM port number. Apple® Macintosh computers recognize the document reader as a USB
CDC class device and automatically use a class driver. Scanning the code below changes the terminal ID to 130.
Note: No extra configuration (e.g., baud rate) is necessary.
CTS/RTS Emulation
ACK/NAK Mode
USB Keyboard (PC)
USB Keyboard (Mac)
USB Japanese Keyboard (PC)
USB HID Barcode Reader
USB COM Port Emulation
On
* Off
On
* Off
