10 - 10 4800dr Barcode Guide
Straight 2 of 5 Industrial Default All Straight 2 of 5 Industrial
Settings
R25DFT
6-9
Straight 2 of 5 Industrial *Off R25ENA0 6-9
On R25ENA1 6-9
Straight 2 of 5 Industrial Message
Length Minimum (1 - 48) *4 R25MIN## 6-9
Maximum (1 - 48) *48 R25MAX## 6-9
Straight 2 of 5 IATA Default All Straight 2 of 5 IATA
Settings
A25DFT
6-10
Straight 2 of 5 IATA *Off A25ENA0 6-10
On A25ENA1 6-10
Straight 2 of 5 IATA Message
Length Minimum (1 - 48) *4 A25MIN## 6-10
Maximum (1 - 48) *48 A25MAX## 6-10
Matrix 2 of 5 Default All Matrix 2 of 5
Settings
X25DFT
6-11
Matrix 2 of 5 *Off X25ENA0 6-11
On X25ENA1 6-11
Matrix 2 of 5 Message Length Minimum (1 - 80) *4 X25MIN## 6-11
Maximum (1 - 80) *80 X25MAX## 6-11
Code 11 Default All Code 11
Settings
C11DFT
6-11
Code 11 *Off C11ENA0 6-11
On C11ENA1 6-11
Code 11 Check Digits Required 1 Check Digit C11CK20 6-12
*2 Check Digits C11CK21 6-12
Code 11 Message Length Minimum (1 - 80) *4 C11MIN## 6-12
Maximum (1 - 80) *80 C11MAX## 6-12
Code 128 Default All Code 128
Settings
128DFT
6-12
Code 128 Off 128ENA0 6-12
*On 128ENA1 6-12
ISBT Concatenation *Off ISBENA0 6-12
On ISBENA1 6-12
Code 128 Message Length Minimum (0 - 80) *0 128MIN## 6-13
Maximum (0 - 80) *80 128MAX## 6-13
Code 128 Code Page Code 128 Code Page (*2) 128DCP## 6-13
Telepen Default All Telepen
Settings
TELDFT
6-13
Telepen *Off TELENA0 6-13
On TELENA1 6-13
Telepen Output *AIM Telepen Output TELOLD0 6-13
Original Telepen Output TELOLD1 6-13
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
