1-49
Rev 2 Apr/2004 KMD 250 Pilot's Guide
Section 1
Basic Operation
5. Use the Joystick to place
the cursor in the Surface field
as shown in Figure 1-85.
6. Turn the Rotary Knob to
select either Soft or Hard for
the type of surface as shown in
Figure 1-86. Note that the air-
port icon has changed to reflect
a hard surface runway.
7. Use the Joystick to place
the cursor in the runway
Length field. Use the Rotary
Knob to select the desired
runway length. A value from 0
to 20,000 feet can be entered.
Note that 2000 ft. has been
entered in Figure 1-87.
8. Use the Joystick to place
the cursor in the runway eleva-
tion (Elev) field. Use the
Rotary Knob to select the
desired runway elevation. A
value from -2000 to 30,000 feet
can be entered. See Figure 1-
87.
User Waypoints
Figure 1-86
Figure 1-87
Figure 1-85
