VDL Icon XM Icon Colors Description
Black on a cyan
background. No weather data is currently being
received but previously received data is
being displayed on the present page.
Black on a cyan
background. Weather data is currently being received
from a signal and displayed on the pre-
sent page. XM signal is weak.
Black on a cyan
background. Weather data is currently being received
from a signal and displayed on the pre-
sent page. XM signal is marginal.
Black on a cyan
background. Weather data is currently being received
from a signal and displayed on the pre-
sent page. XM signal is good.
Black on gray. Weather data not being received nor dis-
played on the present page.
Black on gray. Weather data is currently being received
from a signal but not displayed on the
present page.
Black on gray with
red slash Fault with connection or data link radio.
