2-23
SETTING UP A FIS VDL SUBSCRIPTION
At least one subscription must be set up, even to receive the no-charge
services. Up to four different concurrent subscriptions can be set up
depending on the service packages desired.
NOTE: Entering more than four subscriptions will cause previous sub-
scriptions to be overwritten.
NOTE: The following details require selection of a KDR-510 as the
source for datalink weather data.
To set up a subscription, per-
form the following steps:
1. Press the MENU Key to dis-
play the AUX MENU Softkey
as shown in Figure 2-11.
2. Press the AUX MENU
Softkey to display the AUX-
MAIN MENU Page as shown in
Figure 2-12.
3. Turn the Rotary Knob or
move the Joystick to move the
cursor to select FIS
Subscription as shown in
Figure 2-12.
4. Press the SELECT Softkey
to display the AUX-FIS SUB-
SCRIPTION Page as shown in
Figure 2-13. On initial sub-
scription setup the subscription
window will show only blank
spaces as shown in Figure 2-
13, unless services were pre-
provisioned at the factory. In
this case some lines may not
be blank. If adding another
subscription, one or more pre-
vious subscriptions may be dis-
played with the associated
validity period and status.
The unique identifier for the
individual KMD 250 is dis-
played in the FIS DISPLAY ID
window. The unique ID shown
here is 0H100 11KSH.
KMD 250 Pilot's Guide
Section 2
FIS Operation
Rev 4 Aug/2007
FIS Subscriptions
Figure 2-11
Figure 2-12
Figure 2-13
