HP 5/xx Series 4 User Manual
Page 53

English
41
3 How to Install Accessories In Your PC
Installing Mass Storage Devices
Installing a 3.5-inch Disk Drive in the Bottom Shelf
A slim, (1-inch high) 3.5-inch disk drive can be installed in the bottom
shelf.
Disk drives ordered from HP are delivered with mounting rails. You will
need to order drive mounting rails from HP if you order your disk drive
from another supplier.
1 Disconnect the computer’s power supply cord from the power outlet.
2 Remove the computer’s cover.
3 If there is a device in the middle shelf, remove it.
4 If there is no device in the middle shelf, remove the RFI bezel.
5 Remove the two RFI bezels from the bottom shelf.
uno.bk : uno3_ins.fb4 Page 41 Monday, July 21, 1997 12:46 PM
