English 89
6 Technical Information
Specifications
Available Video Resolutions
Depending on the model, your PC has either:
• an integrated 64-bit Ultra VGA controller on a PCI bus with 1 MB of
memory as standard, which can be upgraded to 2 MB, or
• a Matrox MGA Millennium video adapter board with 2MB of memory
as standard, which can be upgraded to 4MB (upgrade module from
HP) or 8MB (upgrade module from Matrox). Details of available
resolutions and the amount of memory required for each resolution
are given after the details for the different operating systems.
The video resolutions available for your PC depend on the operating
system which you have installed and the amount of memory. The tables
below give the typical resolutions for the operating systems: BIOS,
Windows 3.11, Windows 95 and OS/2.
For details of how to obtain further information, see chapter 7,
“Hewlett Packard Support and Information Services”.
BIOS Video Resolutions
Resolution Number of colors Refresh Rate Memory
640 x 480 16, 256, 32K, 64K 60, 72, 75 1 MB
800 x 600 16, 256, 32K, 64K 60, 72, 75
1024 x 768 16, 256 i43, 60, 70, 75
1280 x 1024 16 i43, i45, 60
Resolution Number of colors Refresh Rate Memory
640 x 480 16, 256, 32K, 64K,
16M 60, 72, 75 2 MB
800 x 600 16, 256, 32K, 64K,
16M 60, 72, 75
1024 x 768 16, 256, 32K, 64K i43, 60, 70, 75
1280 x 1024 16, 256 i45, 60, 70, 75
