6 Technical Information
System Board Connectors and Switches
96 English
The settings for different processors at different speeds are a
combination of the settings of switches 1, 2, 3, 4 and 7.
The following processor speeds have been announced by Intel.
Pentium processor Switch1 Switch 2 Switch 3 Switch 4 Switch 7
CPU Frequency 75 MHz
CPU bus Frequency 50 MHz
PCI Frequency 25 MHz
AT Frequency 8.33 MHz Closed Closed Open Open Open
CPU Frequency 90 MHz
CPU bus Frequency 60 MHz
PCI Frequency 30 MHz
AT Frequency 7.5 MHz Closed Open Open Open Closed
CPU Frequency 100 MHz
CPU bus Frequency 66 MHz
PCI Frequency 33 MHz
AT Frequency 8.25 MHz Open Closed Open Open Closed
CPU Frequency 120 MHz
CPU bus Frequency 60 MHz
PCI Frequency 30 MHz
AT Frequency 7.5 MHz Closed Open Closed Open Closed
CPU Frequency 133 MHz
CPU bus Frequency 66 MHz
PCI Frequency 33 MHz
AT Frequency 8.25 MHz Open Closed Closed Open Closed
Pentium processor Switch 1 Switch 2 Switch 3 Switch 4 Switch 7
CPU Frequency 150 MHz
CPU bus Frequency 60 MHz
PCI Frequency 30 MHz
AT Frequency 7.5 MHz Closed Open Closed Closed Closed
CPU Frequency 166 MHz
CPU bus Frequency 66 MHz
PCI Frequency 33 MHz
AT Frequency 8.25 MHz Open Closed Closed Closed Closed
