Level 1 Level 2 Level 3 Level 4 Descriptions
WLAN WPS w/PIN Code - - Configure the wireless network settings using
WPS with a PIN code.
WLAN Status Status - Display the wireless Ethernet link status.
Signal - Display the signal condition.
Channel - Display the channel in use when Status is
Active .
Speed - Display the connection speed when Status is
Active .
SSID - Display SSID.
Comm. Mode - Display the current Communication mode.
MAC Address - - Display the MAC address of the machine.
WLAN Enable - - Turn the wireless interface on or off.
Wi-Fi
Direct Push Button - - Configure your Wi-Fi Direct network settings using
the one-button push method quickly.
PIN Code - - Configure your Wi-Fi Direct network settings using
WPS with a PIN code quickly.
Manual - - Configure your Wi-Fi Direct network settings
manually.
Group Owner - - Set your machine as the Group Owner.
Device Info. Device
Name - View your machine's device name.
SSID - Display the Group Owner's SSID.
IP Address - Display your machine's IP Address.
Status Info. Status - Display the Wi-Fi Direct network status.
Signal - Display the current Wi-Fi Direct network signal
strength.
When your machine acts as Group Owner, the
LCD always displays
Strong .
Channel - Display the channel in use when the Status is
G/O Active or Client Active .
Speed - Display the connection speed when the Status is
G/O Active or Client Active .
I/F Enable - - Enable or disable the Wi-Fi Direct connection.
Network
Reset - - - Restore all network settings of your machine to the
factory settings.
1 On connection to the network, if the machine's ‘Boot Method’ is ‘Auto’ the machine will attempt to set the IP address and Subnet Mask
from a boot server such as DHCP. If a boot server cannot be found, an APIPA IP address will be allocated, such as 169. 254. [001-254].
[000-255]. If the ‘Boot Method’ of the machine is set to ‘Static’, you must manually enter an IP address from the machine's control panel.
[Print Reports]
Level 1 Level 2 Description
Printer Settings - Print the Printer Settings page.
Network Config - Print the Network Configuration Report.
Print File List
(Available only for certain models)
- Print a list of data saved in the memory.
Drum Dot Print - Print the Drum Dot Check Sheet.
WLAN Report - Print the wireless LAN connectivity diagnosis result.
325
