STI-SNCI

The STI-SNCI interface board allows access to the sync input connections on the EP drive. The STI-SNCI plugs

directly into the J10 connector on the bottom of the drive. The numbers printed on the connector label correlate to

the screw terminal numbers.

Shield connection points are connected from the shell of the "D" connector to the faston lug connector.

Figure 49:

STI-SNCI Drive Sync In Breakout Board

Do not allow ESD directly to terminals. Always discharge static electricity to enclosure, not the drive when
performing maintenance.

1 2 3 4
5 6 7 8
