16
Safety Information Product Overview Installation Diagnostics
Options and
Accessories
Specification
Line Fusing and Wire Size
You must incorporate over current protection for the incoming AC power with the rating shown here.
UL approval for operation with the circuit breakers identified in the table below is pending. At present, fuses
shown must be used for installation to meet UL.
Use copper conductors only. Conductors must be rated 75°C or higher, preferably 90°C.
.
This inrush current specification assumes the drive has been powered off for at least 8 minutes at 40ºC (104ºF)
ambient or 5 minutes at 25ºC (77ºF) ambient. If this amount of time has not elapsed since power off, the inrush
current will be higher.
Drive Model
Recommended
Minimum AC/PE
Line Wire Gauge
Fuse Miniature Circuit Breaker
Fuse Class & Action Bussman
Ferraz-
Shawmut
Allen Bradley Square D
EP202
16 AWG
ISO 1,5
RK1 Time-Delay LPN-RK-6SP A2D6R
1489-A1D060
6 A, 1 pole
60124
6 A. 1 pole
RK1 Quick-Acting KTN-R-6 A2K6R
CC Time-Delay LP-CC-6 ATDR6
1489-A2 D060
6 A, 2 pole
60158
6 A, 2 pole
CC Quick-Acting KTK-R-6 ATMR6
EP204
16 AWG
ISO 1,5
RK1 Time-Delay LPN-RK-10SP A2D10R
1489-A1D100
10 A, 1 pole
60127
10 A, 1 pole
RK1 Quick-Acting KTN-R-10 A2K10R
CC Time-Delay LP-CC-10 ATDR10
1489-A2D100
10 A, 2 pole
60161
10 A, 2 pole
CC Quick-Acting KTK-R-10 ATMR10
EP206
14 AWG
ISO 2,5
RK1 Time-Delay LPN-RK-15SP A2D15R
1489-A1D150
15 A, 1 pole
60129
15 A, 1 pole
RK1 Quick-Acting KTN-R-15 A2K15R
CC Time-Delay LP-CC-15 ATDR15
1489-A2D150
15 A, 2 pole
60263
15 A, 2 pole
CC Quick-Acting KTK-R-15 ATMR15
The Protective Earth (PE) wire connection is mandatory for human safety and proper operation. This
connection must not be fused or interrupted by any means. Failure to follow proper PE wiring can cause death
or serious injury.
Drive Model
Input Voltage
(Vac)
Frequency
(Hz)
Input Current (Amps RMS) at
Full Drive Output Current
Inrush Current
(Amps)
EP202
240 / 1 Ø 47 - 63
5.0 40 (5 ms)
EP204 8.5 65 (5 ms)
EP206 12.0 100 (5 ms)
