55
Other Functions
Saving/Loading the Macro Settings
You can group together the macro settings (1–100) into a single file (.RMC) and save it to a USB flash drive connected to the USB MEMORY port.
You can access the saved macro setting file on the USB flash drive and load it into the unit for use when needed.
NOTE
¹ When using a USB flash drive for the first time, you must
format it using the V-160HD (p. 64).
¹ Never turn off the power or remove the USB flash drive while
the message “PLEASE WAIT” is shown.
¹ Depending on the USB flash drive, recognition of the flash
drive might take some time.
Saving a new file
1 . Connect the USB flash drive to the USB MEMORY port.
2 . [MENU] button
Ó
“MACRO”
Ó
select “SAVE TO USB
MEMORY,” and press the [VALUE] knob.
The macro setting files in the USB flash drive are listed.
3 . Use the [VALUE] knob to select “NEW FILE...,” and press
the [VALUE] knob.
4 . Enter the file name.
* You can enter a text string of up to 16 characters in length.
Use the [VALUE] knob to move the cursor.
Pressing the [EXIT] button deletes the character at the cursor
location.
Press the [VALUE] knob to highlight the character at the
cursor location.
Use the [VALUE] knob to change the character, and press the
[VALUE] knob.
5 . When you finish entering the name, use the [VALUE] knob
to select “SAVE,” and press the [VALUE] knob.
A confirmation message appears.
* If you decide to cancel, press the [EXIT] button.
6 . Use the [VALUE] knob to select “YES,” and press the
[VALUE] knob.
The macro settings file (.RMC) is saved to the USB flash drive. When
the operation is finished, the message “COMPLETE” appears.
7 . Press the [MENU] button to close the menu.
Overwrite-saving
1 . Connect the USB flash drive to the USB MEMORY port.
2 . [MENU] button
Ó
“MACRO”
Ó
select “SAVE TO USB
MEMORY,” and press the [VALUE] knob.
The macro setting files in the USB flash drive are listed.
3 . Use the [VALUE] knob select the macro settings file that
you want to overwrite, and press the [VALUE] knob.
A confirmation message appears.
* If you decide to cancel, press the [EXIT] button.
4 . Use the [VALUE] knob to select “YES,” and press the
[VALUE] knob.
The macro settings file is overwritten. When the operation is
finished, the message “COMPLETE” appears.
5 . Press the [MENU] button to close the menu.
