Operation
66
6.4.11 Electrical
The screen MENU>VIEW>ELECTRICAL shows the major electrical system variables. These quanti-
ties are updated continuously.
Figure 81 Electrical view
6.4.12 Vitals
MENU>VIEW>VITALS shows the current vital system values. These quantities are updated continu-
ously.
Figure 82 Vitals view
6.4.13 Security
Security levels can be changed in the MENU>SECURITY screen.
NOTE
Positive values for DC BUS CURRENT and OUTPUT POWER indicate Discharge mode and
negative values for same indicate Charge mode.
HOME DONE
>>
>>
>>
>>
>> INT. BUS VOLTAGE:
EXT. BUS VOLTAGE:
DC BUS CURRENT:
OUTPUT POWER:
STATUS OF CHARGE: 500
500
100
50
65.78
V
V
A
Kw
%
HOME DONE
>>
>>
>>
>> DRAG POWER:
MISER:
RUNOUT:
RPM: 12.34
1.234
0.012
12345 W
C
Mil
RPM
